Add inputs to your ASPEN system easily with the 16i and 32i input-only units. High-resolution, low-noise microphone preamplifiers featuring true 48 V phantom power provide studio-grade mic/line inputs for your audio system. The 1 Gbs ASPEN port ties these units to others in the stack with ultra-low latency of 1.33 ms for the 16i and 1.46 ms for the 32i.
Main Benefits
- Unlimited input expansion
- TCP/IP Ethernet Addressable
- Seamless auto-mixing with PGA™
- 48-channel mix bus with full output matrixing
- Simultaneous multi-point 3rd party and native control
- Ultra-low 1.33 ms near-side latency for real-time audio
Tech Specs
Specifications for SPN16i Unit:
ASPEN port: 1Gbs control and audio data between ASPEN units
Inputs:
SPN16i: 16 mic/line
SPN32i: 32 mic/line
Gain: 0 dB to 56 dB, programmable in 8 dB steps
Input Level: 0 dBu nominal, max 20dBu
Input Impedance: 8 k Ohms differential mode, 2 k Ohms common mode
Phantom Power: True 48 Volt
Dynamic Range: 102 dB
EIN: -127 dBu (20 Hz - 20 kHz, unweighted)
THD + noise: 0.01%
Frequency Response: 20 Hz – 21 kHz ± 1 dB
Latency:
SPN16i: 1.33 ms
SPN32i: 1.46 ms
Contents
- 1 - Power Cord (Part #21499)
- 1 - Cord Plug (Part #21558)
- 8 - 5-position Plug (Part #21580)
- 1 - USB Cable (Part #21713)
- 1 - Patch Cable (Part #21802)
- 1 - Adjustment Tool (Part #35679)
- 1 - Software CD (Part #ASPENNETWIN)
- 1 - Manual
