Sennheiser EK 100 G4-G

Name: Sennheiser EK 100 G4-G
Brand: Sennheiser
SKU: SE-509520
Price: 278.00 EUR
Availability: InStock
Rating: 5 (1 reviews)

product_detail_x2_desktop_ew_g4_ek_100-pi-1_62379658

product_detail_x2_desktop_ca-2-ek-100-pi-2_758439255

278,00 €
(353,06 € incl. VAT)

available: more t. a week

–

Add to cart

Sennheiser EK 100 G4-G

Powerful camera receiver with a lightweight aluminum housing and for evolution wireless G4 100P Series systems. For documentary, Mobile Journalism and audio for video applications.

Features

Powerful camera receiver, easily mounted on any kind of camera
Excellent sound and construction quality
Easy to use and fast setup time
Powerful and reliable wireless transmission
Range: up to 100 meters / 330 feet
Up to 8 hours of operation time

Tech Specs

Frequency range

A: 516 - 558 MHz
Dimensions

Approx. 82 x 64 x 24 mm
Compander

Sennheiser HDX
THD, total harmonic distortion

≤ 0.9 %
Weight

(incl. batteries) approx. 160 g
Audio output

3.5 mm jack socket: +12 dBu (mono, unbalanced)
Signal-to-noise ratio

≥ 110 dBA
Switching bandwidth

up to 42 MHz
Peak deviation

±48 kHz
Nominal deviation

±24 kHz
Operating time

Typically 8 h
Modulation

Wideband FM
Power supply

2 AA batteries, 1.5 V or BA 2015 accupack
Current consumption

at nominal voltage: typ. 180 mA

with receiver switched off: ≤ 25 µA
Adjacent channel rejection

≥ 65 dB
Intermodulation attenuation

≥ 65 dB
Powering

3 V battery / 2.4 V rechargeable battery
Receiving frequency

Max. 1680 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
RF sensitivity

< 1.6 μV for 52 dBA eff S/N
Squelch

low: 5 dBµV, middle: 15 dBµV, high: 25 dBμV
Temperature Range

-10 °C to +55 °C
Receiver Principle

Adaptive diversity
Blocking

≥ 70 dB
